How To Install A 270-Degree Awning To Your Ute Canopy

270-degree awnings are a staple for rapid-setup overland and camping rigs. Because they are freestanding and self-suspended, you don't have to spend time wrangling ground poles or tripping over guy ropes in the middle of your campsite.

However, because these awnings lack ground support, they experience significant leverage and wind loading - they require a rock-solid mounting foundation.

While fitting an awning to a ute can traditionally be awkward and time-consuming, the Utemaster Awning Mount Bracket simplifies the process, getting you away from the workbench and out on your next mission faster.

Here is how to properly mount a 270-degree awning to your Utemaster Centurion Canopy using a Cantilever Roof Rack.

Hardware Requirements and Compatibility

Before starting your installation, confirm your rack configuration is compatible:

  • Compatible racks: Fits the hex cutouts on MK3 and MK4 Cantilever Roof Racks. For a 270° awning on the cantilever rails, the rack must be a MK4 with the cantilever crossbars in the upper position. On a MK3 rack, a 270° awning goes on top mounted crossbars instead (see below).
  • Not compatible: This bracket system does not fit the Utemaster Roof Platform
  • What's included: The Utemaster kit includes a set of 3x Awning Mount Brackets, designed to distribute the weight of heavy freestanding awnings evenly across the rack


Awning Compatibility

The Utemaster Awning Mount Bracket has been explicitly tested and verified with a wide range of industry-leading freestanding awnings:

Brand Compatible Models
Rhino-Rack Batwing 270 (Left and Right), Batwing Compact, Batwing 180, Sunseeker Freestanding 2m, Sunseeker 2.0m with STOW iT, Batwing with STOW iT
Darche / Eclipse FREESTD Hardshell 270, 270 Freestanding + RTT Entry, 270 Freestanding LED (Left and Right), 180 Freestanding LED, Eco Eclipse 270 Left, Eclipse 270 Gen 2 (Left and Right), Eclipse 180 Gen 2, Kozi 270
Bushwakka Adventure Gear Extreme 270 XT, Extreme 270 XT Max, Extreme 180, Baby 180, Square 2m
Alu-Cab 270 Shadow Awning, 2m 270 Shadow Awning, 180 Shadow Awning
RMR 270 Max LED Left and Right (Gen 2), 270 Awning Left and Right, 180 Degree Awning, 2m x 3m Awning, 2.5m x 2.5m Awning
Adventure Kings 270 Tourer XL Freestanding, 2.5m x 2.5m Side Awning, Peregrine 270
23Zero Falcon 270, Falcon X-Treme 270, Raven 180, Peregrine 270 Right
ARB Touring Awning with LED Light Strip, 270 Awning
Oztent Foxwing 270, Foxwing 270 Awning II, Foxwing 180, Foxwing 180A End Panel


If your awning isn't listed above, contact the Utemaster team to confirm fitment before purchasing.

Where to Mount a 270-Degree Awning

There are two places to mount a 270° awning on the Cantilever Roof Rack, and both are equally suitable. Choose the one that suits the rest of your setup.

Option 1: on the cantilever rails. Mount the awning to the cantilever rails with the Utemaster Awning Mount Bracket or the bracket supplied with your awning. This is only suitable on a MK4 Cantilever Roof Rack with the cantilever crossbars in the upper position.

MK4 Cantilever Rack with the cantilever crossbars in the upper position
MK4 Cantilever Rack with the cantilever crossbars in the upper position.

Option 2: on top mounted crossbars. Fit our 1400 mm top mounted crossbars (CR4-CB-1400-3), which sit on top of the cantilever rails and extend past them, and mount the awning with the bracket supplied with it. On a MK3 Cantilever Roof Rack, this is where a 270° awning must go.

Never mount a 270° awning on the outriggers. A 180° awning is fine on the outriggers, the cantilever rails or top mounted crossbars.

Running a roof top tent as well? Fit a top mounted crossbar that sticks out past the tent and mount the awning to that. Not suitable for side-hinging tents, and check the clearance under the tent.

Roof top tent and awning on 1400mm top mounted crossbars
Roof top tent and awning on 1400 mm top mounted crossbars. The awning is held by the bracket supplied with the awning, not the Utemaster Awning Mount Bracket. Not suitable for side-hinging tents; check the clearance under the tent.

Step-by-Step Installation

These steps cover mounting a 270° awning on the cantilever rails with the Utemaster Awning Mount Bracket, on a MK4 Cantilever Roof Rack with the cantilever crossbars in the upper position. If you are mounting to top mounted crossbars, or using the bracket supplied with your awning, follow the awning manufacturer's instructions.

Step 1 - Position the brackets

Locate the hexagonal cutouts running along the cantilever rails of your MK4 Cantilever Roof Rack. Position the three Utemaster Awning Mount Brackets along the cantilever rail, aligning them with the hex cutouts to match the mounting channel spacing on the back of your awning.

Step 2 - Secure the brackets to the cantilever rails

Bolt the brackets into place through the hex cutouts in the cantilever rail, hard against the outside of the rail.

Step 3 - Mount the awning to the brackets

Lift the awning into position and secure the backing channel to the vertical faces of the three brackets using the hardware supplied by your awning manufacturer.

Step 4 - Check door and tent clearances

Before fully tightening, check that the awning clears your Centurion Canopy's side doors when they are fully open. If you are running a roof top tent, mount the awning to a top mounted crossbar that sticks out past the tent instead, and confirm the awning's swing path does not interfere with the tent base or ladder.

Once everything is correctly positioned, torque all fasteners to specification.


Frequently Asked Questions

Do I need a roof rack to mount a 270-degree awning to a ute canopy?
Yes. A 270° awning mounts to the Cantilever Roof Rack, either on the cantilever rails (MK4 with the cantilever crossbars in the upper position) or on top mounted crossbars. Both are equally suitable.
Is the Awning Mount Bracket compatible with the Utemaster Roof Platform?
No. The bracket system is designed specifically for the MK3 and MK4 Cantilever Roof Rack and is not compatible with the Utemaster Roof Platform.
Which side should I mount my awning?
Most 270-degree awnings are available in LHS (driver's side) or RHS (passenger's side) configurations. Choose the side that gives you the best shade and shelter at camp - and confirm your awning variant before ordering.
I have a MK3 Cantilever Rack - will this work?
The Awning Mount Bracket fits MK3 and MK4 racks, but on a MK3 Cantilever Roof Rack a 270° awning must go on top mounted crossbars, not the cantilever rails. 180° awnings can go on the cantilever rails, outriggers or top mounted crossbars.
Can I mount an awning on the outriggers?
Not a 270° awning. A 180° awning is fine on the outriggers.
Can I run an awning and a roof top tent together?
Yes. Fit a top mounted crossbar that sticks out past the tent and mount the awning to that. Not suitable for side-hinging tents; check the clearance under the tent.
My awning brand isn't on the compatibility list - can I still use it?
The list above covers all explicitly tested models. Contact the Utemaster team to confirm compatibility before purchasing.
